What is an Ingress Protection (IP) Rating?

The Protection Index (IP) measures the resistance of a device to DUST and WATER.

IP ratings consist of two digits (eg IP65): these two digits each indicate a different type of protection.
- The first number represents the degree of protection against solid objects and dust.
- The second number represents the degree of protection against water and humidity.

The table below indicates the degree of protection that an index represents.
First number: Protection against solid objects.


Valeur IP	Protection
IP 0x	No protection
IP 1x	Protection against large objects over 50mm in diameter.
IP 2x	Protection against medium sized objects larger than 12.5mm.
IP 3x	Protection against small objects over 2.5mm in diameter.
IP 4x	Protection against small objects larger than 1mm.
IP 5x	Protection against harmful dust accumulation. Safe to touch.
IP 6x	Complete protection against dust. Safe to touch.

Deuxième chiffre : Protection contre l'eau et l'humidité.

Valeur	Protection	Désignation
IP x0	No protection	-
IP x1	Protection against vertical fall of droplets.	Drip protection type I
IP x2	Protection against dripping water up to an angle of 15°	Drip protection type II
IP x3	Protection against watering up to an angle of 60° (10L/min).	Splash proof
IP x4	Protection against watering (10L/min).	Splash proof
IP x5	Protection against watering (12.5L/min).	Splash proof
IP x6	Protection against watering (100L/min).	Waterproof
IP x7	Protection against water up to 30 minutes up to a depth of 1 meter.	Water immersion resistant
IP x8	Total protection against water.	Totally waterproof
IP x9	Protection against high pressure water and humidity of 90% or more.	Moisture resistant

Most Common Ingress Protection:

IP20: the minimum and most widespread protection index in the world of lighting. Luminaires containing this protection index can be installed in all rooms of the house where it does not contain humidity. It indicates that the product has protection against medium-sized objects larger than 12.5 mm.

IP44: this protection index certifies that the product is protected against small objects larger than 1 mm and also against water splashes in all directions. Luminaires with this protection index can be installed in a bathroom (60 cm away from water points), or on an outdoor facade.

IP54: luminaires with this degree of protection can be installed outdoors. It certifies that the product is protected against the incipient accumulation of dust as well as splashing water from any direction.

IP65: This guarantees total protection against dust and high resistance to water splashes from all directions. Luminaires containing this index can be used in a bathroom around the bathtub and shower as well as outdoors.

IP66: Used for outdoor luminaires, the IP66 protection index provides complete protection against dust and large splashes of water.

IP66: used for outdoor luminaires, the protection index. IP66 provides complete protection against dust and large splashes of water.

IP67: luminaires that include this degree of protection are generally used for outdoor use. They are fully protected against dust and also against strong splashes of water. Resistant to rain and the vagaries of the weather, this protection index is ideal for the outdoors.

IP68: Used to illuminate swimming pools, bathtubs or showers, this protection index guarantees protection against total immersion of the luminaires.
